CEL-LEDS35 single high-power multi-band LED（1W、3W）

Model：CEL-LEDS35

Place of Origin：Beijing

Brief introduction：Not yet...

Contact now

Main technical features

1.High energy output of ultraviolet UV and visible VIS

2.Ultra-long service life, up to 100000 hours, LED university photoelectric conversion efficiency, more energy saving.

3.The irradiating head adopts a new type of heat dissipation design, which greatly improves the service life and output energy of the irradiating head.

4.The power supply has rich display content and direct COM output to realize the automation and information processing of the production process.

5.The power supply is controlled by single-chip microcomputer, which can control five LED independently at the same time.

CEL-LEDS35 automatically controls power parameters

Project	Parameters
Power	3W Can control 5 LED at the same time
Control	Basic mode, stroboscopic mode, program mode (order 36)
LED lamp	0.1-3W Self-adapting
Control precision	Temperature monitoring
Time setting	Turn on/off, light intensity, illumination time. Accuracy: 0.01min

LED lamp parameters

Wave length	Item	Parameters
280nm	Input power	200mw
	Woriking current(CW)	25mA
	Pulse (frequency 1kHz, duty cycle 5%)	100mA
	Voltage	8V(CW),10V(PULSE)
	Working environment temperature	-30℃—55℃
365nm，395nm，405nm	Input power	1W/3W
	Voltage	4V
	Working current	Imax 750mA
	Working environment temperature	-20℃ —80℃
420nm，455nm，470nm，500nm，520nm，590nm，620nm，660nm,740nm	Input power	1W/3W
	Voltage	4V
	Working current	Imax 750mA
	Working environment temperature	-20℃ —80℃
810nm,850nm，940nm	Input power	1W/3W
	Voltage	4V
	Working current	Imax 750mA
	Working environment temperature	-20℃ —80℃
